Application

Special feature Free from silicone; Halogen-free; Gold-plated contacts; Drag chain suitability

Free from silicone yes

Electrical data

Operating voltage[V] < 250 AC / < 300 DC

Protection class II

Max. current load total[A] 4

Operating conditions

Ambient temperature[°C] -25...90

Note on ambient temperature

cULus: ...75 °C

Ambient temperature (moving)[°C] -25...90

Note on ambient temperature (moving)

cULus: ...75 °C

Storage temperature[°C] -25...55

Storage humidity[%] 10...100

Other climatic conditions for storage according to stated class

1K22/ DIN 60721-3-1

Protection IP 65; IP 67; IP 68; IP 69K

Mechanical data

Weight[g] 74.9

Dimensions[mm] 15.5 x 15.5 x 45

Materials housing: TPU orange; Sealing: FKM

Material nut brass, nickel-plated

Drag chain suitability yes

Drag chain suitability

bending radius for flexible use min. 10 x cable diameter

travel speed max. 3.3 m/s for a horizontal travel length of 5 m and max. acceleration of 5 m/s²

bending cycles > 5 Mio.

torsional strain ± 180 °/m

Remarks

Notes Please see the technical note under "Downloads"

Pack quantity 1 pcs.

Electrical connection

Cable: 2 m, PUR, Halogen-free, black, Ø 4.3 mm; 4 x 0.34 mm² (42 x Ø 0.1 mm )

Electrical connection - socket

ConnectionConnector: 1 x M12, straight; coding: A; Locking: brass, nickel-plated; Contacts: gold-plated;

Tightening torque: 0.6...1.5 Nm
