Functional principle Photoelectric retro-reflective sensor

Functional principle detail With minimum distance to reflector (dual lens system)

Dimensions (W x H x D) 11 mm x 31 mm x 20 mm

Housing design (light emission) Rectangular

Sensing range max. 0.01 m ... 3 m 1)

Sensing range 0.01 m ... 2.5 m 1)

Type of light Visible red light

Light source LED 2)

Light spot size (distance) Ø 140 mm (2 m)

Wave length 632 nm

Adjustment Potentiometer (Sensitivity)

Special applications Detecting transparent objects

1) Reflector PL80A.

2) Average service life: 100,000 h at TU = +25 °C.

Supply voltage UB 10 V DC ... 30 V DC 1)

Ripple ± 10 % 2)

Current consumption 30 mA 3)

Switching output NPN

Switching mode Light/dark switching

Switching mode selector Selectable via light/dark rotary switch

Signal voltage NPN HIGH/LOW Approx. VS / < 1.8 V

Output current Imax. ≤ 100 mA

Response time ≤ 0.5 ms 4)

Switching frequency 1,000 Hz 5)

Attenuation along light beam ≥ 20 %

Connection type Cable, 3-wire, 2 m 6)

Cable material Plastic, PVC

Conductor cross section 0.18 mm²

Circuit protection

A 7)

B 8)

D 9)

Protection class III

Housing material Plastic, ABS/PC/POM

Optics material Plastic, PMMA

Enclosure rating IP67

Items supplied Mounting bracket BEF-W100-A, Reflector P250

Ambient operating temperature –25 °C ... +55 °C

Ambient temperature, storage –40 °C ... +70 °C

1) Limit values.

2) May not fall below or exceed UV tolerances.

3) Without load.

4) Signal transit time with resistive load.

5) With light/dark ratio 1:1.

6) Do not bend below 0 °C.

7) A = VS connections reverse-polarity protected.

8) B = output reverse-polarity protected.

9) D = outputs overcurrent and short-circuit protected.
